Video Compression
-Support Video Resolution: 080P、2K、4K, etc
-Support Video Parsing Format: H.264、H.265, etc
-Support Video Access Format: RTSP、GB28181、Onvif
Quick Link:
| Video Compression | ||||||||||||
| Processor | ARM | |||||||||||
| Memory | 4GB / 8GB | |||||||||||
| Storage | 32GB / 64G EMMC，Maximum SD card support 128GB | |||||||||||
| Network | RJ45 * 2, Suitable for all telecom operator | |||||||||||
| Interface | HDMI * 1, USB 3.0 *1 / USB 2.0 *1 | |||||||||||
| Video Resolution | 1080P、2K、4K, etc | |||||||||||
| Video Parsing Format | H.264、H.265, etc | |||||||||||
| Video Access Format | RTSP、GB28181、Onvif | |||||||||||
| Operating System | Linux | |||||||||||
| Size | 190mm×114mm×65mm | |||||||||||
| Power Supply | DC 12V/5A | |||||||||||
| Operating Temperature | -20℃~60℃ | |||||||||||
| Storage Temperature | -20℃~85℃ | |||||||||||
| Operating Humidity | 5%~85% non-condensing | |||||||||||
Technology & Feature
-
Supports more than 20 compression levels to match different bandwidth and clarity needs of users.
-
Support 360P (640*360), D1 (704*576), QHD (960*540), 720P (1280*720), 1080P (1920* 1080), 2K (2560*1440), 4K (3840*2160) and other resolutions.
-
Supports up to 16 channels of 1080P video compression +8 channels of AI running at the same time, and video parsing supports 1080P, 2K and 4K,etc.
-
Support compressed video format can be configured,
-
following the input source, H.264, H.265 and other encoding formats.
